SPECIFICATION

1,Working Medium:Purified gas,Standard gas,Corrosive gas

2,Body material:Stainless steel 316L or Brass

3,Cover material:Stainless steel 316L or Brass

4,Filter element material:SS316L

5,Diaphragm Material:SS316L

6,Seat Material:PTFE

7,Spring Material:SS316L

8,Poppet Material:SS316L

9,Working Temperature:-40~74℃

8,Filtration fineness:10µ

9,Mounting type: Panel mounting or Wall mounting

10,Regulator type:Diaphragm type

11,Maximum input pressure:500PSI, 1500PSI,3000PSI

12,Output pressure:0~15PSI,0~25PSI,0-50PSI,0-75PSI,0-100PSI,0-125PSI,0-250PSI,0~500PSI

11,Port size:Inlet 1/4NPT,1/2NPT,3/4NPT,Outlet 1/4NPT
